IMSA MF 2000 BB CNC DEEP HOLES DRILLING MACHINE FOR DIES
Technical specifications
| Manufacturer | IMSA |
| Model | MF 2000 BB CNC |
| Year | 2011 |
| Stock Number | MF-2000-BB |
| Max. working Ø | 50 mm. |
| Max. working lenght | 2.000 mm. |
| Spindle power | 17 kw. |
| Spindle speeds | 4.200 rpm. |
| Table | 2.500 x 2.000 mm. |
| Table travel | 800 mm. |
| Transversal travel | 3.250 mm. |
| Vertical travel | 1.500 mm. |
| Cnc | CNC HEIDENHAIN TNC 530 |
| Total weight | 45 Tons. |
Features and Accessories
Complete with:
- rotary table
- swivelling head +/- 20°
- milling/threading spindle
- 20 seats atc
- fixing table 2.500 x 2.200 mm.
- chipconveyor
- drilling and milling tools
