P. CARNAGHI AC 20 CNC VERTICAL BORER
No longer available
Technical specifications
| Manufacturer | P. CARNAGHI |
| Model | AC 20 CNC |
| Year | 1980 |
| Table Ø | 2.000 mm. |
| Max. working Ø | 2.500 mm. |
| Spindle power | 59 Kw. |
| Max. working height | 1.800 mm. |
| Max. weight on table | 25 Tons. |
| Table speeds | 2,7 ÷ 190 Rpm. |
| RAM type vertical tool travel | 1.250 mm. |
| Turret type vertical tool travel | 800 mm. |
| RAM size | 240 x 240 mm. |
| Cnc | CNC ICEM |
| Total weight | 40 Tons. |
Features and Accessories
Retrofitted in 2002
Complete with:
- n. 2 cnc vertical tools
- chipconveyor
- full covered
